FEATURES
Low DC resistance, high rated current and high inductance. Inductance: 0.15 to 560 micro H.
The series exhibits low voltage drops and smal variations in inductance with respect to temperature rise and DC current level. This makes them excellent for use as power supply line choke coils.
The series has excellent solder heat resistance Both flow and reflow soldering methods can be emploved.
APPLICATION
Our products are widely used in communication, network, digital television, household appliance, consumer electronics, automotive electronics, industrial equipment and instrument, etc.
